AOC 2236Swa Service Manual

73
C900 065G306M3322BP Y1 CAP 3300PF M 250VAC
C925 067G215S1023LV LOW ESR EC 1000uF 16V M 10*20mm
C918 067G215S1024KV EC 1000UF 20% 25V 12.5*20
C804 067G215S1024KV EC 1000UF 20% 25V 12.5*20
C922 067G215S4713KV
EC 105℃ CAP 470UF M 16V
C604 067G215S4713LV LOW ESR EC 470uF 16V M 10*12.5mm
C921 067G215V1023KS EC 1000uF M 16V 12.5*16mm
C907 067G315Z10115K EC 100UF 20% 450V 18*40
L901 073G 174 65 H2 LINE FILTER 30mH MIN
L906 073G 253 91 H IND CHOKE 3.5uH+-10% DADONG
L905 073G 253 91 H IND CHOKE 3.5uH+-10% DADONG
L907 073G 253 91 L CHOKE BY LI TA
T901 080GL22T 3 N1 X'FMR 490uH YUVA-1093
PT801 080GL24T 23 DN X'FMR 68uH TK.2005Y.101 VOC
CN901 087G 501 32 DL AC SOCKET DIP 3PIN+2PIN GROUND
CN601 088G 30214K DC PHONE JACK 5P GREEN -
CN902 095G 825 9WE04 HARNESS 9P-9P 150mm
705GH893009 D901/D906 ASS'Y
705GHA57002 Q901 ASS'Y
709G2892 HM001 CONSUMPTIVE ASS'Y
HS3 Q90G6295 3 HEAT SINK
L801 S73G17435VA
COMMON FILTER CHOKE 200mH±25%
L802 S73G17435VA
COMMON FILTER CHOKE 200mH±25%
IC601 056G 616 51 IC APA2071JI-TUG 3.1W DIP-16
BD901 093G 50460502 BRIDGE KBP206G C2
USB9HA1 USB G2663-2-X-X-1-090313
CN511 033G3802 5 BH L CONNECTOR 5PIN
CN512 088G 352 2 XH USB CONN
715G2663 2 USB BOARD PCB
USBAHA5 USB G3501-2-X-X-1-090313
CN501 033G3802 5B Y L CONNECTOR 5P 2.0
CN502 088G 351 2B XH USB CONN B TYPE 4P - -
E09508 095G8014 5DH09 HARNESS 5P(PH)-5P(PLUG) 180MM
E09508 095G8014 5TH09 HARNESS 5P(PLUG)-5P(2501) 180MM 2nd source
E09508 095G8014 5WH09 HARNESS 5P(PLUG)-5P(2501) 180MM 2nd source
C503 065G0603104 12 CER2 0603 X7R 16V 100N P
C501 065G0603509 31 CHIP 5PF +-0.5PF 50V NPO
C502 065G0603509 31 CHIP 5PF +-0.5PF 50V NPO
FB501 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF
715G3501 2 USB BOARD PCB
Q55G 100625 TIN STICK_LOW ARGENTUM
D901 093G 52 66 DIODE FMX-12SL 10A/200V TO-220
D906 093G 60278 SCHOTTKY SP1060 10A 60V ITO-220AB
0M1G 930 8120 SCREW
HS2 Q90G6264 5 HEAT SINK
Q901 057G 667918 MOSFET SMK0870F
HS1 090G6064 1 HEAT SINK
0M1G 930 8120 SCREW
Q55G 100625 TIN STICK_LOW ARGENTUM
E55 055G 23524 WELDING FLUX WITHOUT PB
Q51G 6 4509 GLUE_RTV
IC901 056G 379128 IC LD7576 GS SOP-8
IC801 056G 608 12 IC ta9687GN-A-0-TR SOP-16
Q802 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM
