AOC 24B2H2 User Manual

9
Connecting the Monitor
Cable Connections In Back of Monitor:
2 31
1. HDMI
2. Earphone
3. Power
Connect to PC
1. Connect the power cord to the back of the display rmly.
2. Turn o󰀨 your computer and unplug its power cable.
3. Connect the display signal cable to the video connector on your computer.
4. Plug the power cord of your computer and your display into a nearby outlet.
5. Turn on your computer and display.
If your monitor displays an image, installation is complete. If it does not display an image, please refer Troubleshooting.
To protect equipment, always turn o󰀨 the PC and LCD monitor before connecting.

AOC 24B2H2 Specifications

General

Panel Type	IPS
Refresh Rate	75Hz
Aspect Ratio	16:9
Brightness	250 cd/m²
Contrast Ratio	1000:1
Response Time	4 ms (GtG)
Viewing Angles	178°(H)/178°(V)
Inputs	HDMI 1.4, VGA
Color Gamut	72% NTSC
VESA Mount	100x100mm
Resolution	1920 x 1080
Screen Size	23.8 inches
