AOC 24B2H2 User Manual

23
Specification
General Specification (24B2H2)
Panel
Model name 24B2H2
Driving system TFT Color LCD
Viewable Image Size 60.47cm diagonal
Pixel pitch 0.2745(H)mm x 0.2745(V) mm
Display Color 16.7M Colors
Others
Horizontal scan range 30k-115kHz
Horizontal scan Size(Maximum) 527.04mm
Vertical scan range 48-100Hz
Vertical Scan Size(Maximum) 296.46mm
Optimal preset resolution 1920x1080@60Hz
Max resolution 1920x1080@100Hz
Plug & Play
VESA DDC2B/CI
Power Source 19Vdc,1.31A
Power Consumption
Typical(default brightness and contrast) 17W
Max. (brightness = 100, contrast =100) ≤ 25W
Standby mode ≤0.3W
Physical
Characteristics
Connector Type HDMIx2/Earphone
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°C~ 40°C
Non-Operating -25°C~ 55°C
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0 ~ 5000 m (0~ 16404ft )
Non-Operating 0 ~ 12192m (0~ 40000ft )

AOC 24B2H2 Specifications

General

Panel Type	IPS
Refresh Rate	75Hz
Aspect Ratio	16:9
Brightness	250 cd/m²
Contrast Ratio	1000:1
Response Time	4 ms (GtG)
Viewing Angles	178°(H)/178°(V)
Inputs	HDMI 1.4, VGA
Color Gamut	72% NTSC
VESA Mount	100x100mm
Resolution	1920 x 1080
Screen Size	23.8 inches
