19" LCD Color Monitor AOC 917Vw
16
5.2 Electrical Block Diagram
5.2.1 Main Board
Flash Memory
PM25LV010A
(U402)
Panel Interface
(CN301)
SCK
SCZ
Crystal
14.31818MHZ
(X201)
Keypad Interface
(CN201)
Scalar TSUM56AWHL-LF-1
(Include MCU, ADC, OSD)
(U202)
D-Sub
Connector
(CN101)
EEPROM
M24C02
(U101)
H sync
V sync
RGB
DDC1_SDA,
DDC1_SCL
DVI
Connector
(CN103)
EEPROM
M24C02
(U102)
D-Data
D-Clock
DDC2_SDA,
DDC2
_
SCL
EEPROM
AF24BC04-SI
(U204)
http://www.wjel.net
