19" LCD Color Monitor AOC 917Vw
31
8.2 Trouble Shooting
8.2.1 Main Board
(1). No Power
No power
Press power key and look
if the picture is normal
Please reinsert and make sure
the AC of 100-240 is normal
Reinsert or check the
Adapter/Inverter
section
X201 oscillate waveforms
are normal
Replace U701 or U702
Replace U202
Replace X201
OK
OK
OK
NG
NG
NG
NG
Measure U702 PIN2=1.8V
Measure U701 PIN2=3.3V
