AOC 917vw Service Manual

19" LCD Color Monitor AOC 917Vw
7
3.3 OSD Menu
OSD Function Introduction
Luminance Adjust Range Description
Brightness 0-100 Backlight Adjustment
Contrast 0-100 Contrast from Digital-register
Standard
Standard Mode
Text
Text Mode
Internet
Internet Mode
Game Game Mode
Movie
Movie Mode
Eco mode
Sports Sports Mode
Gamma1
Adjust to Gamma 1
Gamma2
Adjust to Gamma 2
Gamma
Gamma3 Adjust to Gamma 3
Off Disable dynamic contrast ratio
DCR
On
Enable dynamic contrast ratio
Image Setup
Clock 0-100 Adjust picture Clock to reduce Vertical-Line noise.
Focus 0-100 Adjust Picture Phase to reduce Horizontal-Line noise
H.Position 0-100 Adjust the horizonal position of the picture.
V.Position 0-100 Adjust the vertical position of the picture
Color Temp.
Warm Recall Warm Color Temperature from EEPROM.
Normal Recall Normal Color Temperature from EEPROM.
