AOC 917vw Service Manual

19" LCD Color Monitor AOC 917Vw
4
1. Monitor Specifications
Model number 917Vw
Driving system TFT Color LCD
Viewable Image Size 481mm
Pixel pitch 0.2835mm(H) x 0.2835mm(V)
R, G, B Analog lnterface
Video
Digital Interface
Separate Sync. H/V TTL
Display Color 16.7M Colors
LCD Panel
Max. Dot Clock 135 MHz
Horizontal scan range 30 kHz - 83 kHz
Horizontal scan Size(Maximum) 408.24mm
Vertical scan Size(Maximum) 255.15mm
Vertical scan range 55 Hz - 75 Hz
Optimal preset resolution 1440 x 900 (60 Hz)
Highest preset resolution 1440 x 900 (60 Hz)
Plug & Play VESA DDC2B/CI
D-Sub 15pin
Input Connector
DVI 24pin
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM, Positive
Power Source 100~240VAC, 47~63Hz
Active < 37W
Resolution
Power Consumption
Standby < 1W
Temperature:
Operating 0° to 40°
Non-Operating -20°to 60°
Humidity:
Operating 15% to 90% (non-condensing)
Non-Operating 15% to 90% (non-condensing)
Altitude:
Operating 0~ 2439m (0~ 8000 ft )
Environmental
Non-Operating 0~ 12192m (0~ 40000 ft )
