AOC 917vw Service Manual

19" LCD Color Monitor AOC 917Vw
41
CN201 033G3802 6 WAFER
CN401 033G3802 9 WAFER 9P RIGHT ANELE PITCH
CN301 033G801930F CH JS CONNECTOR
R402 061G152M519 64 5.1OHM 2W
C303 067G 3151014KV
EC 105℃ CAP 100UF M 25V
C402 067G 3151014KV
EC 105℃ CAP 100UF M 25V
C403 067G 3151014KV
EC 105℃ CAP 100UF M 25V
C407 067G 3151014KV
EC 105℃ CAP 100UF M 25V
C408 067G 3151014KV
EC 105℃ CAP 100UF M 25V
C202 067G215V100 7R LOW E.S.R 10UF +/-20% 50V
C209 067G215V100 7R LOW E.S.R 10UF +/-20% 50V
C220 067G215V100 7R LOW E.S.R 10UF +/-20% 50V
CN101 088G 35315F HD D-SUB CONN F ATTACHED SCREW
CN103 088G 35424F D DVI 24PIN CONN F ATTACHED SCREW
X201 093G 2253B H XAT01431AFI1H-3OHX AT-49 14.31818MHZ
U202 056G 562547 IC TSUM56AWHL-LF-1 MSTAR
U702 056G 563 31 IC AZ1117D-1.8-E1
U701 056G 585 4A AP1117E33LA
U101 056G1133 34 M24C02-WMN6TP
U102 056G1133 34 M24C02-WMN6TP
U204 056G1133104 IC AF24BC04-SI 4K SOIC-8
U402 056G1133713 IC PM25LV010A-100SCE SOIC-8
Q201 057G 417 12 T KEC 2N3904S-RTK/PS
Q205 057G 417 12 T KEC 2N3904S-RTK/PS
Q403 057G 417 12 T KEC 2N3904S-RTK/PS
Q202 057G 417 13 T KEC 2N3906S-RTK/PS
Q203 057G 417 13 T KEC 2N3906S-RTK/PS
Q301 057G 417 13 T KEC 2N3906S-RTK/PS
Q302 057G 763 1 A03401 SOT23 BY AOS(A1)
R138 061G0402000 RST CHIPR 0 OHM +-5% 1/16W
R139 061G0402000 RST CHIPR 0 OHM +-5% 1/16W
R201 061G0402000 RST CHIPR 0 OHM +-5% 1/16W
R136 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R133 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R131 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R130 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R129 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R128 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R127 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
R126 061G0402100 RST CHIPR 10 OHM +-5% 1/16W
