Adjusting

Hotkeys

1 2 3 4 5

1 Source/Auto/Exit

2 Game Mode/<

3 Dial Point/>

4 Menu/Enter

5 Power

Power

Press the Power button to turn on the monitor.

Menu/Enter

When there is no OSD, Press to display the OSD or conrm the selection. Press about 2 second to turn off the monitor.

Game Mode/<

When there is no OSD, press ”<” key to open game mode function, then press ”<” or “>” key to select game mode (FPS,

RTS, Racing, Gamer 1, Gamer 2 or Gamer 3) basing on the different game types.

Dial Point/>

When there is no OSD, press Dial Point button to show / hide Dial Point.

Source/Auto/Exit

When the OSD is closed, press Source/Auto/Exit button will be Source hot key function.

When the OSD is closed, press Source/Auto/Exit button continuously about 2 second to do auto congure (Only for the

models with D-Sub).

Questions and Answers:

Need help?

Do you have a question about the AOC C24G1A and is the answer not in the manual?

AOC C24G1A Specifications

General

Panel type	VA
Color depth	8 bit
Pixel pitch	0.2715 x 0.2715 mm
Pixel density	9334 ppi
Backlight type	W-LED
Display diagonal	23.6 \
Screen curvature	1500 mm
Surface hardness	3H
Adobe RGB coverage	98 %
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 146 Hz
Horizontal scan range	30 - 160 kHz
NTSC coverage (typical)	99 %
Screen curvature rating	1500R
Viewable size, vertical	293.28 mm
sRGB coverage (typical)	114 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	521.39 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Certification	ISO
Product color	Black, Red
Detachable stand	Yes
Market positioning	Gaming
VESA mounting	-
Tilt angle range	-4 - 21.5 °
Height adjustment	130 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, ENG, ESP, FIN, FRE, ITA, JPN, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A+++ to D
Power consumption (standby)	0.5 W
Power consumption (typical)	31 W
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Number of upstream ports	4
Compatibility	TUV, CE, EAC, ISO 9241-307 class I
AMD FreeSync type	FreeSync Premium
AMD FreeSync refresh rate range	48 - 144 Hz
Mean time between failures (MTBF)	50000 h
Cables included	AC, DisplayPort, HDMI
DisplayPort cable length	1.8 m
Package depth	180 mm
Package width	741 mm
Package height	408 mm
Package weight	9940 g
