Page #4 background image
2
Power
The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the
type of power supplied to your home, consult your dealer or local power company.
The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will t
only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an
electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of
the grounded plug.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the
monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in re or electric shock.
To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate congured
receptacles marked between 100-240V AC, Min. 5A.
The wall socket shall be installed near the equipment and shall be easily accessible.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AOC C24G1A and is the answer not in the manual?

AOC C24G1A Specifications

General IconGeneral
Panel typeVA
Color depth8 bit
Pixel pitch0.2715 x 0.2715 mm
Pixel density9334 ppi
Backlight typeW-LED
Display diagonal23.6 \
Screen curvature1500 mm
Surface hardness3H
Adobe RGB coverage98 %
Display technologyLED
Native aspect ratio16:9
Vertical scan range48 - 146 Hz
Horizontal scan range30 - 160 kHz
NTSC coverage (typical)99 %
Screen curvature rating1500R
Viewable size, vertical293.28 mm
sRGB coverage (typical)114 %
Contrast ratio (dynamic)80000000:1
Contrast ratio (typical)3000:1
Display number of colors16.78 million colors
Viewable size, horizontal521.39 mm
Display brightness (typical)250 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
CertificationISO
Product colorBlack, Red
Detachable standYes
Market positioningGaming
VESA mounting-
Tilt angle range-4 - 21.5 °
Height adjustment130 mm
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CZE, DEU, ENG, ESP, FIN, FRE, ITA, JPN, POL, POR, RUS, SWE
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA+++ to D
Power consumption (standby)0.5 W
Power consumption (typical)31 W
DisplayPort version1.2
Headphone connectivity3.5 mm
Number of upstream ports4
CompatibilityTUV, CE, EAC, ISO 9241-307 class I
AMD FreeSync typeFreeSync Premium
AMD FreeSync refresh rate range48 - 144 Hz
Mean time between failures (MTBF)50000 h
Cables includedAC, DisplayPort, HDMI
DisplayPort cable length1.8 m
Package depth180 mm
Package width741 mm
Package height408 mm
Package weight9940 g
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)174 mm
Width (with stand)600 mm
Height (with stand)514 mm
Weight (with stand)4510 g
