AOC C24G2 User Manual

12
Adjusting
Hotkeys
1 2 3 4 5
1 Source/Auto/Exit
2 Game Mode/<
3 Dial Point/>
4 Menu/Enter
5 Power
Power
Press the Power button to turn on the monitor.
Menu/Enter
When there is no OSD, Press to display the OSD or conrm the selection. Press about 2 second to turn off the monitor.
Game Mode/<
When there is no OSD, press ”<” key to open game mode function, then press ”<” or “>” key to select game mode (FPS,
RTS, Racing, Gamer 1, Gamer 2 or Gamer 3) basing on the different game types.
Dial Point/>
When there is no OSD, press Dial Point button to show / hide Dial Point.
Source/Auto/Exit
When the OSD is closed, press Source/Auto/Exit button will be Source hot key function.
When the OSD is closed, press Source/Auto/Exit button continuously about 2 second to do auto congure (Only for the
models with D-Sub).

AOC C24G2 Specifications

General

Panel type	VA
Pixel pitch	0.2715 x 0.2715 mm
Display diagonal	23.6 \
Display technology	-
Native aspect ratio	16:9
NTSC coverage (typical)	99 %
Screen curvature rating	1500R
Viewable size, vertical	293.28 mm
sRGB coverage (typical)	120 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	521.39 mm
Display brightness (typical)	250 cd/m²
Product color	Black
Market positioning	Home
HDMI	Yes
HDMI version	1.4
DisplayPort version	1.2
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	- W
Power consumption (typical)	21 W

Weight and Dimensions

Depth (with stand)	227.4 mm
Height (with stand)	505.3 mm
Weight (with stand)	4350 g
Depth (without stand)	68.5 mm
Width (without stand)	536.1 mm
Height (without stand)	321 mm
Weight (without stand)	2990 g
