AOC C32G1 User Manual

Picture Bounces, Flickers Or
Wave Pattern Appears In The
Move electrical devices that may cause electrical interference as far away
from the monitor as possible.
Use the maximum refresh rate your monitor is capable of at the resolution
you are using.
Monitor Is Stuck In Active
Off-Mode"
The Computer Power Switch should be in the ON position.
The Computer Video Card should be snugly fitted in its slot.
Make sure the monitor's video cable is properly connected to the computer.
Inspect the monitor's video cable and make sure no pin is bent.
Make sure your computer is operational by hitting the CAPS LOCK key on
the keyboard while observing the CAPS LOCK LED. The LED should either
turn ON or OFF after hitting the CAPS LOCK key.
Missing one of the primary
colors (RED, GREEN, or
BLUE)
Inspect the monitor's video cable and make sure that no pin is damaged.
Make sure the monitor's video cable is properly connected to the computer.
Screen image is not centered
or sized properly
Adjust H-Position and V-Position or press hot-key (AUTO).
Picture has color defects
(white does not look white)
Adjust RGB color or select desired color temperature.
Horizontal or vertical
disturbances on the screen
Use Windows7/8/10 shut-down mode to adjust CLOCK and PHASE.
Press to auto-adjust.
46

AOC C32G1 Specifications

General

3D	No
Panel type	VA
Color depth	8 bit
Pixel pitch	0.3637 x 0.3637 mm
Backlight type	W-LED
Display diagonal	31.5 \
Screen curvature	1800 mm
Adobe RGB coverage	90 %
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 146 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	1080p
Screen curvature rating	1800R
Viewable size, vertical	392.85 mm
sRGB coverage (typical)	122 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	698.4 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Tilt angle range	-5 - 21.5 °
Height adjustment	-
Cable lock slot type	Kensington
Number of OSD languages	16
On Screen Display (OSD)	Yes
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
HDMI version	1.4
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Cables included	AC, DisplayPort, HDMI
HDMI cable length	1.8 m
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	50 W
Package type	Box
Package depth	242 mm
Package width	807 mm
Package height	551 mm
Package weight	9100 g
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Certification	ISO
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
AMD FreeSync type	FreeSync Premium
AMD FreeSync refresh rate range	30 - 144 Hz
Sustainability certificates	REACH, RoHS, EPEAT Silver, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	244.9 mm
Width (with stand)	713.1 mm
Height (with stand)	560.3 mm
Weight (with stand)	6980 g
Depth (without stand)	81.8 mm
Width (without stand)	425.4 mm
Weight (without stand)	5670 g
