Page #63 background image
Warranty Statement for North & South America (excluding Brazil)
WARRANTY STATEMENT
for AOC Color Monitors
Including those Sold within North America as Specified
Envision Peripherals, Inc. warrants this product to be free from defects in material and workmanship for a period of
three (3) years for parts & labor and one (1) year for CRT Tube or LCD Panel after the original date of consumer
purchase. During this period, EPI ( EPI is the abbreviation of Envision Peripherals, Inc. ) will, at its option, either
repair the defective product with new or rebuilt parts, or replace it with a new or rebuilt product at no charge except
as *stated below. The parts or product that are replaced become the property of EPI.
In the USA to obtain service under this limited warranty, call EPI for the name of the Authorized Service Center
closest to your area. Deliver the product freight pre-paid, along with the dated proof of purchase, to the EPI
Authorized Service Center. If you cannot deliver the product in person:
Pack it in its original shipping container (or equivalent)
Put the RMA number on the address label
Put the RMA number on the shipping carton
Insure it (or assume the risk of loss/damage during shipment)
Pay all shipping charges
EPI is not responsible for damage to inbound product that was not properly packaged.
EPI will pay the return shipment charges within one of the countries specified within this warranty statement. EPI is
not responsible for any costs associated with the transportation of product across international borders. This
includes the international borders of the countries within this warranty statements.
In the United States and Canada contact your Dealer or EPI Customer Service, RMA Department at the toll free
number (888) 662-9888. Or you can request an RMA Number online at www.aoc.com/na-warranty.
* This limited warranty does not cover any losses or damages that occur as a result of:
Shipping or improper installation or maintenance
Misuse
Neglect
Any cause other than ordinary commercial or industrial application
Adjustment by non-authorized source
Repair, modification, or installation of options or parts by anyone other than an EPI Authorized Service Center
Improper environment
Excessive or inadequate heating or air conditioning or electrical power failures, surges, or other irregularities
This three-year limited warranty does not cover any of the product's firmware or hardware that you or any third
party have modified or altered; you bear the sole responsibility and liability for any such modification or alteration.
63

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AOC C32G1 and is the answer not in the manual?

AOC C32G1 Specifications

General IconGeneral
3DNo
Panel typeVA
Color depth8 bit
Pixel pitch0.3637 x 0.3637 mm
Backlight typeW-LED
Display diagonal31.5 \
Screen curvature1800 mm
Adobe RGB coverage90 %
Display technologyLED
Native aspect ratio16:9
Vertical scan range48 - 146 Hz
Horizontal scan range30 - 160 kHz
Supported video modes1080p
Screen curvature rating1800R
Viewable size, vertical392.85 mm
sRGB coverage (typical)122 %
Contrast ratio (dynamic)80000000:1
Contrast ratio (typical)3000:1
Display number of colors16.78 million colors
Viewable size, horizontal698.4 mm
Display brightness (typical)250 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
Tilt angle range-5 - 21.5 °
Height adjustment-
Cable lock slot typeKensington
Number of OSD languages16
On Screen Display (OSD)Yes
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
HDMI version1.4
DisplayPort version1.2
Headphone connectivity3.5 mm
Cables includedAC, DisplayPort, HDMI
HDMI cable length1.8 m
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
Power consumption (typical)50 W
Package typeBox
Package depth242 mm
Package width807 mm
Package height551 mm
Package weight9100 g
Recyclable packaging material100 %
Mean time between failures (MTBF)50000 h
CertificationISO
Product colorBlack
Heavy metals freeHg (mercury)
Market positioningGaming
AMD FreeSync typeFreeSync Premium
AMD FreeSync refresh rate range30 - 144 Hz
Sustainability certificatesREACH, RoHS, EPEAT Silver, ENERGY STAR
Operating altitude0 - 5000 m
Non-operating altitude5000 - 12192 m
Storage temperature (T-T)-25 - 55 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 93 %
Operating relative humidity (H-H)10 - 85 %
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)244.9 mm
Width (with stand)713.1 mm
Height (with stand)560.3 mm
Weight (with stand)6980 g
Depth (without stand)81.8 mm
Width (without stand)425.4 mm
Weight (without stand)5670 g
