AOC CU34G2 User Manual

13
Luminance
Luminance Color Setup Picture Boost OSD Setup ExitExtra
Contrast 50
Brightness 90
Eco mode Standard
Gamma Gamma1
DCR Off
HDR Mode Off
PIP Setting
PIP
Game Setting
Contrast 0-100 Contrast from Digital-register.
Brightness 0-100 Backlight Adjustment
Eco mode
Standard Standard Mode
Text Text Mode
Internet Internet Mode
Game Game Mode
Movie Movie Mode
Sports Sports Mode
Reading Reading Mode
Uniformity Uniformity Mode
Gamma
Gamma1 Adjust to Gamma 1
Gamma2 Adjust to Gamma 2
Gamma3 Adjust to Gamma 3
DCR
O󰀨 Disable dynamic contrast ratio
On Enable dynamic contrast ratio
HDR
(CU34G2X)
O󰀨
Adjust HDR Mode
Note:
When HDR is detected, the HDR option is
displayed for adjustment. When HDR is not
detected, the HDR Mode option is displayed for
adjustment.
DisplayHDR
HDR Picture
HDR Movie
HDR Game
HDR Mode
O󰀨
Adjust HDR Mode
HDR Picture
HDR Movie
HDR Game
Note:
The function MBR and Overdrive Boost are available only when Adaptive-Sync is o󰀨 and the vertical frequency is up to
75 Hz.

AOC CU34G2 Specifications

General

3D	-
Panel type	VA
Color depth	6 bit
Pixel pitch	0.2745 x 0.2745 mm
Backlight type	W-LED
Display diagonal	34 \
Screen curvature	1500 mm
Surface hardness	3H
Adobe RGB coverage	92 %
Display technology	LED
Native aspect ratio	21:9
Vertical scan range	50 - 146 Hz
Horizontal scan range	30 - 160 kHz
NTSC coverage (typical)	85 %
Screen curvature rating	1500R
Viewable size, vertical	333.72 mm
sRGB coverage (typical)	124 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	86.4 cm
Viewable size, horizontal	797.22 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
On/off switch	Yes
Exterior finish type	Textured
Recyclable packaging material	100 %
AMD FreeSync type	FreeSync
AMD FreeSync refresh rate range	48 - 100 Hz
Certification	True
Product color	Black, Red
Front bezel color	Black/Red
Heavy metals free	Hg (mercury)
Market positioning	Gaming
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Number of upstream ports	4
VGA (D-Sub) ports quantity	0
Tilt angle range	-5 - 23 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	55 W
Cables included	DisplayPort, HDMI
Power cable length	1.8 m
Package depth	280 mm
Package width	903 mm
Package height	548 mm
Package weight	9470 g
Sustainability certificates	WEEE
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	132.37 mm
Height (with stand)	398.16 mm
Weight (with stand)	8000 g
Depth (without stand)	48 mm
Width (without stand)	808.34 mm
Height (without stand)	367.45 mm
Weight (without stand)	6500 g
