Wall Mounting

Preparing to Install An Optional Wall Mounting Arm.

This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this

procedure. Follow these steps:

1. Remove the base.

2. Follow the manufacturer’s instructions to assemble the wall mounting arm.

3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in

the back of the monitor.

4. Insert the 4 screws into the holes and tighten.

5. Reconnect the cables. Refer to the user’s manual that came with the optional wall mounting arm for

instructions on attaching it to the wall.

100mm

Specication of wall hanger screws

：

M4*(10+X)mm, ( X=Thickness of Wall mount bracket )

M=4.0Max

Dk=8.0±0.2

H=2.0±0.1

L=10+X

D3.86-3.96

M4-P0.7

NOTE: VESA mounting screw holes are not available for all models, please check with the dealer or

ofcial department of AOC. Always contact manufacturer for wall-mount installation.

-5°

0° 90°

* Display design may differ from those illustrated.

WARNING:

1. To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward

by more than -5 degrees.

2. Do not press the screen while adjusting the angle of the monitor. Grasp only the bezel.

Questions and Answers:

Need help?

Do you have a question about the AOC CU34G2XP and is the answer not in the manual?

AOC CU34G2XP Specifications

General

Haze rate	25 %
Panel type	VA
Pixel pitch	0.23175 x 0.23175 mm
Pixel density	109.7 ppi
Backlight type	W-LED
Display diagonal	34 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	21:9
Maximum refresh rate	180 Hz
NTSC coverage (typical)	105.4 %
Screen curvature rating	1500R
sRGB coverage (typical)	126.5 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	4000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	86.4 cm
High Dynamic Range (HDR) technology	DisplayHDR 400
RMS rated power	4 W
Number of speakers	2
LED indicators	Operation, Stand-by
Tilt angle range	3.5 - 21.5 °
Height adjustment	130 mm
Cable lock slot type	Kensington
HDCP version	2.2
Headphone outputs	1
Charging port type	USB Type-A
DisplayPort version	1.4
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50/60 Hz
Power consumption (max)	120 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	59 W
Package depth	903 mm
Package width	280 mm
Package height	548 mm
Package weight	8020 g
Feet color	Black/Red
Product color	Black
Market positioning	Gaming
