AOC CU34G2XP User Manual

14
Luminance
Luminance Color Setup Picture Boost OSD Setup ExitExtra
Contrast 50
Brightness 70
Eco mode Standard
Gamma Gamma1
DCR Off
HDR Mode Off
PIP Setting
PIP
Game Setting
Contrast 0-100 Contrast from Digital-register.
Brightness 0-100 Backlight Adjustment
Eco mode
Standard Standard Mode
Text Text Mode
Internet Internet Mode
Game Game Mode
Movie Movie Mode
Sports Sports Mode
Reading Reading Mode
Uniformity Uniformity Mode
Gamma
Gamma1 Adjust to Gamma 1
Gamma2 Adjust to Gamma 2
Gamma3 Adjust to Gamma 3
DCR
Off Disable dynamic contrast ratio
On Enable dynamic contrast ratio
HDR
Off
Adjust HDR Mode
Note:
When HDR is detected, the HDR option is
displayed for adjustment. When HDR is not
detected, the HDR Mode option is displayed
for adjustment.
DisplayHDR
HDR Picture
HDR Movie
HDR Game
HDR Mode
Off
Adjust HDR Mode
HDR Picture
HDR Movie
HDR Game
Note:
The function MBR and Overdrive Boost are available only when AMD FreeSync Premium is off and the
vertical frequency is up to 75 Hz.

AOC CU34G2XP Specifications

General

Haze rate	25 %
Panel type	VA
Pixel pitch	0.23175 x 0.23175 mm
Pixel density	109.7 ppi
Backlight type	W-LED
Display diagonal	34 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	21:9
Maximum refresh rate	180 Hz
NTSC coverage (typical)	105.4 %
Screen curvature rating	1500R
sRGB coverage (typical)	126.5 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	4000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	86.4 cm
High Dynamic Range (HDR) technology	DisplayHDR 400
RMS rated power	4 W
Number of speakers	2
LED indicators	Operation, Stand-by
Tilt angle range	3.5 - 21.5 °
Height adjustment	130 mm
Cable lock slot type	Kensington
HDCP version	2.2
Headphone outputs	1
Charging port type	USB Type-A
DisplayPort version	1.4
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50/60 Hz
Power consumption (max)	120 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	59 W
Package depth	903 mm
Package width	280 mm
Package height	548 mm
Package weight	8020 g
Feet color	Black/Red
Product color	Black
Market positioning	Gaming

Weight and Dimensions

Depth (with stand)	237.4 mm
Width (with stand)	808.3 mm
Height (with stand)	528.2 mm
Weight (with stand)	12000 g
Depth (without stand)	102.9 mm
Height (without stand)	367.5 mm
Weight (without stand)	6510 g
