AOC e2050Swd Service Manual

48
C926
065G080510432K Y
CAP CHIP 0805 100N 50V X7R +/-10%
C912
065G080510432K Y
CAP CHIP 0805 100N 50V X7R +/-10%
C807
065G080522432K Y
CAP CHIP 0805 220N 50V X7R +/-10%
C806
065G080522432K Y
CAP CHIP 0805 220N 50V X7R +/-10%
C804
065G080547432K T
CAP CHIP 0805 0.47UF K 50V X7R
C811
065G080547432K T
CAP CHIP 0805 0.47UF K 50V X7R
C810
065G080547432K T
CAP CHIP 0805 0.47UF K 50V X7R
C808
065G120610171J Y
CAP 1206 100PF 5% 500V NP0
C929
065G120622272K Y
CER 1206 2N2 500V X7R 10%
C928
065G120622272K Y
CER 1206 2N2 500V X7R 10%
C916
065G120622272K Y
CER 1206 2N2 500V X7R 10%
C917
065G120622272K Y
CER 1206 2N2 500V X7R 10%
709G4744 HS001
CONSUMPTIVE ASS'Y
SW003
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
SW004
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
SW005
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
SW001
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
SW002
077G603S AI HJ
TACT SWITCH AI 2PIN SEALED
E715
715G4747K02000001C
KEY PCB FR1 SS 135*11*1.6mm
J810
095G 90 23
JUMP WIRE - -
J811
095G 90 23
JUMP WIRE - -
J812
095G 90 23
JUMP WIRE - -
J813
095G 90 23
JUMP WIRE - -
J814
095G 90 23
JUMP WIRE - -
J815
095G 90 23
JUMP WIRE - -
J901
095G 90 23
JUMP WIRE - -
J902
095G 90 23
JUMP WIRE - -
J903
095G 90 23
JUMP WIRE - -
J904
095G 90 23
JUMP WIRE - -
J905
095G 90 23
JUMP WIRE - -
J906
095G 90 23
JUMP WIRE - -
J907
095G 90 23
JUMP WIRE - -
J909
095G 90 23
JUMP WIRE - -
J910
095G 90 23
JUMP WIRE - -
J921
095G 90 23
JUMP WIRE - -
CN901
006G 31500
EYELET
IC903
056G 158 10 T
DC/DC AS431AZTR-E1 150MA 40V TO-92
Q904
057G 530503 T
2SD1207T
R915
061G 17222052T TZ
RST CFR 22R 5% 1/4W
R906
061G152M10452T SY
RST MOFR 100KOHM +-5% 2WS FUTABA
R904
061G152M25152T SY
RST MOF 250R 5% 2W
R924
061G152M47852T SY
RST MOFR 0.47 OHM +-5% 2WS FUTABA
C911
065G 2K152 2T6921
CAP CER 1500pF K 2KV Y5P
C805
065G250K1052HT
CAP CER 1UF 10% 25V X7R
C902
065G305M1023WR
CAP Y2 1NF 20% 250V Y5U
C903
065G305M1023WR
CAP Y2 1NF 20% 250V Y5U
C900
065G306M22233R
CAP Y1 2.2NF 20% 250V Y5U
C927
065G500K4732HT
CAP CER 47NF 10% 50V X7R
C816
065G517K102 2T6921
CAP CER 1000PF K 500V Y5P
C920
067G 2046812KT
CAP CS 680UF 20% 10V 8*11 3900mA GP1A6
C801
067G215D3314KT
EC 330UF 20% 25V 10*12 ED
C913
067G215Y4707KT
EC 47uF 20% 50V 6.3*11mm EG

AOC e2050Swd Specifications

General

Color	glossy black, black
Screen Type	led
Webcam	no
OS Compatibility	windows
Screen Size	20 inches
Aspect Ratio	16:9
Resolution	1600 x 900
Native Resolution	1600 x 900
Refresh Rate	60hz
Horizontal Viewing Angle	90 degrees
Vertical Viewing Angle	50 degrees
Response Time	5 milliseconds
Brightness	200 candela per square meter
Contrast Ratio	20, 000, 000:1
Horizontal Scan Rate	83 kilohertz
VGA Ports	1
DVI	1
Power Saving Mode	0.5 watts
Power Consumption	17 watts
Width with Stand	18.8 inches
Net Weight without Stand	6.2 pounds
