AOC e2050Swd Service Manual

49
FB801
071G 55 29
FERRITE BEAD
FB802
071G 55 29
FERRITE BEAD
FB901
071G 55 29
FERRITE BEAD
FB902
071G 55 29
FERRITE BEAD
FB903
071G 55 29
FERRITE BEAD
F902
084G 56 4 B
FUSE 4A 250V
F901
084G 56 4 B
FUSE 4A 250V
ZD901
093G 39A6852T
ZENER MTZJ22B 21.51V 0.5W DO-35
D903
093G 6026T52T
CTIFIER DIODE FR107
D907
093G 6452452T
SWITCHING 1N4148-B4006 0.2A 100V DO-35
J808
095G 90 23
JUMP WIRE - -
J807
095G 90 23
JUMP WIRE - -
J806
095G 90 23
JUMP WIRE - -
J805
095G 90 23
JUMP WIRE - -
J804
095G 90 23
JUMP WIRE - -
J803
095G 90 23
JUMP WIRE - -
J802
095G 90 23
JUMP WIRE - -
J801
095G 90 23
JUMP WIRE - -
J809
095G 90 23
JUMP WIRE - -
J908
095G 90 23
JUMP WIRE - -
C922
367G415X4713AT
EC 470uf 20% 16V 10X13 RS
C918
367G415X6814AT
EC 680uf 20% 25V 10x20 RS
709G4744 HA001
CONSUMPTIVE ASS'Y
E715
715G4744P01003001C
PWR PCB FR1 SS 193X132+1.6(mm)
2nd source
E715
715G4744P01003001M
PWR PCB FR1 SS 193*132*1.6mm
D904
093G 6026T52T
CTIFIER DIODE FR107
U401
056G 562368
SCALER NT68660FG/B TQFP-100
U701
056G 563515
LDO AZ1117D-3.3TR/E1 1A/3.3V TO-252
U104
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
U107
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
U106
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
U103
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
U102
056G 662 52
ESD PROTECT AZC398-04S.R7G SOT23-6
U101
056G1133 34 1
EEPROM M24C02-RMN6TP 2Kb SO-8
U105
056G1133 34 1
EEPROM M24C02-RMN6TP 2Kb SO-8
U402
056G2233501
FLASH MX25L2026DM1I-12G 2Mb SOP-8
Q401
057G 417517
Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q402
057G 417517
Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q706
057G 417518
TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q701
057G 417518
TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q705
057G 763940
MOSFET AO3401A SOT-23
R453
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R410
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R409
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R407
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R406
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R118
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R117
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R110
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R109
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R104
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
R103
061G0402000 JT
RST 0402 0.05R MAX 1/16W -

AOC e2050Swd Specifications

General

Color	glossy black, black
Screen Type	led
Webcam	no
OS Compatibility	windows
Screen Size	20 inches
Aspect Ratio	16:9
Resolution	1600 x 900
Native Resolution	1600 x 900
Refresh Rate	60hz
Horizontal Viewing Angle	90 degrees
Vertical Viewing Angle	50 degrees
Response Time	5 milliseconds
Brightness	200 candela per square meter
Contrast Ratio	20, 000, 000:1
Horizontal Scan Rate	83 kilohertz
VGA Ports	1
DVI	1
Power Saving Mode	0.5 watts
Power Consumption	17 watts
Width with Stand	18.8 inches
Net Weight without Stand	6.2 pounds
