AOC E2236VW User Manual

21.5" LCD Color Monitor AOC e2236Vw
79
E08905 089G 175 8A G USB CABLE 1800MM without PE bag 2nd source
E08902 089G 715CAAE01 SIGNAL CABLE 2nd source
E08902 089G 715GAAE01 SIGNAL CABLE 2nd source
E08902 089G 715HAAE01 SIGNAL CABLE
E08903 089G1745CAA 9 DVI CABLE 1500 2nd source
E08903 089G1745GAA 9 DVI CABLE 2nd source
E08903 089G1745HAA 9 DVI CABLE 1.5M
E08901 089G404A15N HL AC POWER CORD 1500mm
E08901 089G404A15N IS AC POWER CORD 1500 2nd source
H40G 001624 1A CARTON LABEL BARCODE 1
H40G 22N61534A ID LABEL
H40G000261587A AP BOXSTIKER LABEL
Q41G78D161522A Vietnam warranty
GND1 009G6005 1 GND TERMINAL
GND2 009G6005 1 GND TERMINAL
GND3 009G6005 1 GND TERMINAL
CN903 033G380210B Y L CONNECTOR 10P 2.0
IC902 056G 139 3A PC123Y22FZOF SHARP
NR901 061G 58100 X NTCR 10R 20% 5W(10D2-14 MCS)
C904 063G107K2246S1 X2 CAP 0.22UF K 275VAC
C902 065G306K3312B3 Y1 CAP 330PF K 250VAC CD
C903 065G306K3312B3 Y1 CAP 330PF K 250VAC CD
C900 065G306M1022BP CAP Y1 1NF 20% 250V Y5U
C918 067G 3151007KV CAP 105C 10UF M 50V
C907A 067G 40Z10115L EC 100uF 450V M 18*35.5mm
C912 067G215D6814LV LOW ESR EC 680uF 25V M 10*20mm
C914 067G215S4713KV EC 470UF 20% 16V 10X13
L901 073G 174 65 H2 LINE FILTER 30mH MIN
L902 073G 253 91 H IND CHOKE 3.5uH+-10% DADONG
L903 073G 253 91 H IND CHOKE 3.5uH+-10% DADONG
T901 080GL19P 1 N X'FMR 1.1mH 10% 20uH MAX YUVA-1208
CN901 087G 501 32 DL AC SOCKET DIP 3PIN+2PIN GROUND
D903 093G 60335 DIODE SR515 5A/150V DO-201AD
D905 093G 60335 DIODE SR515 5A/150V DO-201AD
D904 093G 60923 DIODE SR504-30 DO-201AD
D906 093G 60923 DIODE SR504-30 DO-201AD
CN902 095G 825 9DE08 HARNESS 9P-9P 200MM
CN902 095G 825 9XE08 HARNESS 9P-9P 200MM 2nd source
E09502 095G801410DE06 HARNESS 10P(1253)-10P(PLUG) 310MM 2nd source
E09502 095G801410TE06 HARNESS 10P(1253)-10P(PLUG) 310MM
705GH956024 IC901 ASS'Y
709G3189 HM001 COMSUPTIVE ASS'Y
H40G 45762429A LABEL
BD901 093G 50460514 BRIDGE KBP306G-05 3A 800V KBP
CN402 033G3802 7B Y L CONNECTOR 7P 2.0
CN701 033G3802 9B Y L CONN 2.0 9P
CN301 033G801930F CH JS FFC CONN 1.0mm 30P R/A 34mm 6.3mm
R708 061G152M33964L SY RST MOFR 3.3 OHM +-5% 2WS SHANG YU
CN101 088G 35315F CH D-SUB CONN WITH SCREW 15P
CN102 088G 35424F CH DVI 24PIN CONN F ATTACHED SCREW
X401 093G 2253B J NXS14.31818AC32F-KAB10
709G3329 HM003 CONSUMPTIVE ASS'Y
H40G 45762429A LABEL
A33G0564 2 1L0100 Key-Guide
H52G1201 1 3M DOUBLE FACE TAPE
C802 067G 4151017LV EC 100uF 20% 50V RZY 8*11.5

AOC E2236VW Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size diagonal	547 mm
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	2000000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
DVI-I ports quantity	0
Certification	cCSAus, FCC, CE, EPA, Win 7, ROHS, CCC, TUV/S, TUV
Product color	Black
LED indicators	Power
Tilt angle range	-5 - 20 °
Number of OSD languages	15
Panel mounting interface	- mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Package depth	129 mm
Package width	588 mm
Package height	389 mm
Package weight	5600 g

Weight and Dimensions

Depth (with stand)	206 mm
Width (with stand)	531 mm
Height (with stand)	396.57 mm
Weight (with stand)	4100 g
Weight (without stand)	- g
