AOC E2236VW User Manual

21.5" LCD Color Monitor AOC e2236Vw
80
C804 067G415L330 9L EC 33UF 20% 100V 8*11.5
709G3823 HM001 COMSUPTIVE ASS'Y
H40G 45762429A LABEL
CN511 033G3802 5 BH L CONNECTOR 5PIN
CN512 088G 352 2 XH USB CONN A TYPE 4P
709G2663 HM002 CONSUMPTIVE ASS'Y
715G2663 3 USB BOARD PCB
CN501 033G3802 5B Y L CONNECTOR 5P 2.0
CN502 088G 351 2B XH USB CONN B TYPE 4P
E09508 095G8014 5DH09 HARNESS 5P(PH)-5P(PLUG) 180MM
E09508 095G8014 5TH09 HARNESS 5P(PLUG)-5P(2501) 180MM 2nd source
E09508 095G8014 5WH09 HARNESS 5P(PLUG)-5P(2501) 180MM 2nd source
709G3501 HM001 CONSUMPTIVE ASS'Y
IC901 056G 581 20 IC TOP255EN eSIP-7C
0M1G 930 8120 SCREW 3x8
Q11G0026 1 WIRE-CLIP
HS1 Q90G6263 6 HEAT SINK
Q51G 6 4509 GLUE_RTV
Q55G 100625 TIN STICK_LOW ARGENTUM
R623 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R628 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R917 061G06031001FT RST CHIP 1K 1/10W 1%
R913 061G06031002FT RST CHIP 10K 1/10W 1%
R912 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN
R916 061G0603471 JT RST CHIPR 470OHM +-5% 1/10W TZAI YUAN
R915 061G06039311FT RST CHIPR 9.31k 1% 1/10W
R923 061G0805103 JT RST 0805 10K 5% 1/8W
R903 061G08051102FT RST CHIP 11K 1/8W 1%
R924 061G0805689 JT RST CHIPR 6.8 OHM +-5% 1/8W 0805
R925 061G08058202FT RST CHIPR 82K +-1% 1/8W TZAI YUAN
R927 061G12060004JT RST CHIPR 1206 MAX0R05 4A 1/4W TZAI YUAN
R910 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R926 061G1206229 JT RST CHIPR 2R2 +-5% 1/4W TZAI YUAN
R909 061G1206300 JT RST CHIPR 30 OHM +-5% 1/4W TZAI YUAN
R908 061G1206300 JT RST CHIPR 30 OHM +-5% 1/4W TZAI YUAN
R907 061G1206300 JT RST CHIPR 30 OHM +-5% 1/4W TZAI YUAN
R906 061G1206300 JT RST CHIPR 30 OHM +-5% 1/4W TZAI YUAN
R905 061G1206300 JT RST CHIPR 30 OHM +-5% 1/4W TZAI YUAN
R904 061G1206300 JT RST CHIPR 30 OHM +-5% 1/4W TZAI YUAN
R920 061G1206335 JT RST CHIPR 3.3 MOHM +-5% 1/4W TZAI YUAN
R921 061G1206335 JT RST CHIPR 3.3 MOHM +-5% 1/4W TZAI YUAN
R922 061G1206335 JT RST CHIPR 3.3 MOHM +-5% 1/4W TZAI YUAN
R900 061G1206624 JT RST CHIPR 620 KOHM +-5% 1/4W TZAI YUAN
R901 061G1206624 JT RST CHIPR 620 KOHM +-5% 1/4W TZAI YUAN
R902 061G1206624 JT RST CHIPR 620 KOHM +-5% 1/4W TZAI YUAN
C916 065G060310312K F NO-SUGGEST 0603 10NF K 16V X7R
C905 065G080510432K F CAP CHIP 0805 0.1UF K 50V X7R
C915 065G080510432K Y CAP CHIP 0805 100N 50V X7R +/-10%
C917 065G080510432K Y CAP CHIP 0805 100N 50V X7R +/-10%
C901 065G080582031J F CAP CHIP 0805 82PF J 50V NPO
C910 065G120622272K Y CER 1206 2N2 500V X7R 10%
C911 065G120622272K Y CER 1206 2N2 500V X7R 10%
C919 065G120622272K Y CER 1206 2N2 500V X7R 10%
C920 065G120622272K Y CER 1206 2N2 500V X7R 10%
709G3189 HS001 COMSUPTIVE ASS'Y
Q55G 100625 TIN STICK_LOW ARGENTUM

AOC E2236VW Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size diagonal	547 mm
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	2000000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
DVI-I ports quantity	0
Certification	cCSAus, FCC, CE, EPA, Win 7, ROHS, CCC, TUV/S, TUV
Product color	Black
LED indicators	Power
Tilt angle range	-5 - 20 °
Number of OSD languages	15
Panel mounting interface	- mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Package depth	129 mm
Package width	588 mm
Package height	389 mm
Package weight	5600 g

Weight and Dimensions

Depth (with stand)	206 mm
Width (with stand)	531 mm
Height (with stand)	396.57 mm
Weight (with stand)	4100 g
Weight (without stand)	- g
