AOC E2236VW User Manual

21.5" LCD Color Monitor AOC e2236Vw
81
C419 067G 3151007KB EC 10uF M 50V 5*11mm EG
C707 067G 3151014KB EC LOW ESR 100UF M 25V 6.3*11mm EG
C704 067G 3151014KB EC LOW ESR 100UF M 25V 6.3*11mm EG
C305 067G 3151014KB EC LOW ESR 100UF M 25V 6.3*11mm EG
709G3329 HA003 CONSUMPTIVE ASS'Y
U401 056G 562F31 SCALER TSUMU58PWHL-LF-1 100PIN FQFP
U703 056G 563 31 IC AZ1117D-1.8-E1
U701 056G 585 4A AP1117E33L-13-77 1A 3.3V SOT-223
U107 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U106 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U105 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U104 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U103 056G 662 48 ESD PROTECT AZC399-04S.R7G SOT23-6L
U101 056G1133 34 EEPROM M24C02-WMN6TP 2Kb SO-8
U102 056G1133 34 EEPROM M24C02-WMN6TP 2Kb SO-8
U402 056G1133137 IC MX25L2026MI-12G SOP-8 2nd source
U402 056G2233501 FLASH MX25L2026DM1I-12G 2Mb SOP-8
Q401 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q302 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q701 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q405 057G 417526 SMALLTRAN MMBT3906 -0.2A -40V SOT-23
Q301 057G 763 1 MOSFET A03401 4.2A 30V SOT-23
R414 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
R418 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
R419 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
R423 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
R434 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
R452 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA
R134 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
R132 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
R131 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
R130 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
R129 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
R128 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
R127 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
R126 061G0402100 JF RST CHIPR 10 OHM +-5% 1/16W FENGHUA
R119 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R409 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R415 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R416 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R417 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R422 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R424 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R428 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R706 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R118 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R117 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R115 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R114 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R113 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R111 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R109 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R105 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R101 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R705 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA
R404 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA

AOC E2236VW Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size diagonal	547 mm
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	2000000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
DVI-I ports quantity	0
Certification	cCSAus, FCC, CE, EPA, Win 7, ROHS, CCC, TUV/S, TUV
Product color	Black
LED indicators	Power
Tilt angle range	-5 - 20 °
Number of OSD languages	15
Panel mounting interface	- mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Package depth	129 mm
Package width	588 mm
Package height	389 mm
Package weight	5600 g

Weight and Dimensions

Depth (with stand)	206 mm
Width (with stand)	531 mm
Height (with stand)	396.57 mm
Weight (with stand)	4100 g
Weight (without stand)	- g
