AOC E2236VW User Manual

21.5" LCD Color Monitor AOC e2236Vw
82
R402 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA
R104 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA
R103 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA
R703 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R702 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R436 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R412 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R407 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R308 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R305 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R135 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R133 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R120 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA
R421 061G0402104 JF RST CHIPR 100KOHM +-5% 1/16W FENGHUA
R107 061G0402222 JF RST CHIPR 2.2KOHM +-5% 1/16W FENGHUA
R106 061G0402222 JF RST CHIPR 2.2KOHM +-5% 1/16W FENGHUA
R304 061G0402223 JF RST CHIPR 22KOHM 5% 1/16W FENGHUA
R406 061G0402223 JF RST CHIPR 22KOHM 5% 1/16W FENGHUA
R704 061G0402223 JF RST CHIPR 22KOHM 5% 1/16W FENGHUA
R401 061G04023900FF RST CHIPR 390 OHM +-1% 1/16W FENGHUA
R432 061G04023901FF RST CHIPR 3.9KOHM +-1% 1/16W FENGHUA
R433 061G04023901FF RST CHIPR 3.9KOHM +-1% 1/16W FENGHUA
R110 061G0402471 JF RST CHIPR 470 OHM 5% 1/16W FENGHUA
R303 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA
R138 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA
R137 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA
R136 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA
R125 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA
R124 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA
R123 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA
R306 061G0402563 JF RST CHIPR 56KOHM 1/16W FENGHUA
R139 061G0402682 JF RST CHIPR 6.8KOHM +-5% 1/16W FENGHUA
R116 061G0402750 JF RST CHIPR 75 OHM +-5% 1/16W FENGHUA
R112 061G0402750 JF RST CHIPR 75 OHM +-5% 1/16W FENGHUA
R108 061G0402750 JF RST CHIPR 75 OHM +-5% 1/16W FENGHUA
R102 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R405 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R461 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R456 061G0603220 JF ST CHIPR 22 OHM +-5% 1/10W FENGHUA
R301 061G1206221 JF RST CHIPR 220 OHM +-5% 1/4W FENGHUA
R302 061G1206221 JF RST CHIPR 220 OHM +-5% 1/4W FENGHUA
C107 065G040210232K Y CAP CHIP 0402 1N 50V X7R +/-10%
C121 065G040210232K Y CAP CHIP 0402 1N 50V X7R +/-10%
C122 065G040210232K Y CAP CHIP 0402 1N 50V X7R +/-10%
C413 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C414 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C415 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C416 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C417 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C422 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C432 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C701 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C702 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C705 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C708 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C709 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

AOC E2236VW Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size diagonal	547 mm
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	2000000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
DVI-I ports quantity	0
Certification	cCSAus, FCC, CE, EPA, Win 7, ROHS, CCC, TUV/S, TUV
Product color	Black
LED indicators	Power
Tilt angle range	-5 - 20 °
Number of OSD languages	15
Panel mounting interface	- mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Package depth	129 mm
Package width	588 mm
Package height	389 mm
Package weight	5600 g

Weight and Dimensions

Depth (with stand)	206 mm
Width (with stand)	531 mm
Height (with stand)	396.57 mm
Weight (with stand)	4100 g
Weight (without stand)	- g
