AOC E2236VW User Manual

21.5" LCD Color Monitor AOC e2236Vw
83
C712 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C713 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C115 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C124 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C301 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C304 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C403 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C404 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C405 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C406 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C407 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C408 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C409 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C410 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C411 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C412 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C436 065G0402105A5K Y NO-SUGGEST CAP 0402 1UF 10% 10V X5R
C103 065G040222031J Y CAP CHIP 0402 22P 50V NP0 +/-5%
C104 065G040222031J Y CAP CHIP 0402 22P 50V NP0 +/-5%
C116 065G040222415K Y CAP CHIP 0402 220nF 16V X5R
C117 065G040222415K Y CAP CHIP 0402 220nF 16V X5R
C302 065G040222415K Y CAP CHIP 0402 220nF 16V X5R
C401 065G040222415K Y CAP CHIP 0402 220nF 16V X5R
C421 065G040247031J Y CAP 0402 47PF 5% 50V NP0
C420 065G040247031J Y CAP 0402 47PF 5% 50V NP0
C114 065G040247312K Y CAP 0402 47NF 10% 16V X7R
C111 065G040247312K Y CAP 0402 47NF 10% 16V X7R
C110 065G040247312K Y CAP 0402 47NF 10% 16V X7R
C108 065G040247312K Y CAP 0402 47NF 10% 16V X7R
C106 065G040247312K Y CAP 0402 47NF 10% 16V X7R
C102 065G040247312K Y CAP 0402 47NF 10% 16V X7R
C113 065G040250931C Y CAP 0402 5PF 0.25pF 50V NP0
C109 065G040250931C Y CAP 0402 5PF 0.25pF 50V NP0
C105 065G040250931C Y CAP 0402 5PF 0.25pF 50V NP0
C303 065G060310522K T CAP CHIP 0603 1uF K 25V X7R
C402 065G0805475A5K Y CAP CHIP 0805 4.7UF K 10V X5R
FB301 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB410 071G 56V301 M CHIP BEAD 0805 300R 25% 700mA
FB404 071G 56V301 M CHIP BEAD 0805 300R 25% 700mA
FB402 071G 56V301 M CHIP BEAD 0805 300R 25% 700mA
FB401 071G 56V301 M CHIP BEAD 0805 300R 25% 700mA
FB110 071G 59G301 EM CHIP BEAD 0603 300R 25% 200mA
FB105 071G 59G301 EM CHIP BEAD 0603 300R 25% 200mA
FB104 071G 59G301 EM CHIP BEAD 0603 300R 25% 200mA
FB103 071G 59K190 M CHIP BEAD 0603 19R/500mA
FB102 071G 59K190 M CHIP BEAD 0603 19R/500mA
FB101 071G 59K190 M CHIP BEAD 0603 19R/500mA
D104 093G 64 42 L DIODE LBAV70LT1G SOT-23 LRC
D108 093G 64 42 L DIODE LBAV70LT1G SOT-23 LRC
ZD104 093G 39GA01 T RLZ5.6B
709G3329 HS003 CONSUMPTIVE ASS'Y
715G3329 1 2 MAIN BOARD PCB
H52G1701 1 MESH PRINTTING_PAPER
CN001 033G8034 6H H L1 CONN 1.0mm 6P R/A - -
U001 056G 669 10 TOUCH KEY CG7246AMT QFN-16(COL)
R012 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN

AOC E2236VW Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size diagonal	547 mm
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	2000000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
DVI-I ports quantity	0
Certification	cCSAus, FCC, CE, EPA, Win 7, ROHS, CCC, TUV/S, TUV
Product color	Black
LED indicators	Power
Tilt angle range	-5 - 20 °
Number of OSD languages	15
Panel mounting interface	- mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Package depth	129 mm
Package width	588 mm
Package height	389 mm
Package weight	5600 g

Weight and Dimensions

Depth (with stand)	206 mm
Width (with stand)	531 mm
Height (with stand)	396.57 mm
Weight (with stand)	4100 g
Weight (without stand)	- g
