4.3.3 Electrical Characteristics
Parameter Symbol
Values
Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage V
LCD
4.5 5.0 5.5 Vdc
Permissive Power Input Ripple V
LCD
- - 0.3 V 3
Power Supply Input Current
I
LCD-MOSAIC
(60Hz) - 1000 1300 mA 1,5
I
LCD-BLACK
(60Hz) - 1300 1690 mA 2,5
I
LCD-BLACK
(75Hz) - 2000 mA 5
Power Consumption P
LCD
- 5.00 6.5 Watt 1
Inrush current I
RUSH
- - 3.0 A 1, 4
LED bar Electrical characteristics
Parameter Symbol Condition
Values
Unit Notes
Min. Typ. Max.
LED : 1,7
LED String Current Is - 110 120 mA 2,7
LED String Voltage Vs 48.0 51.2 54.4 V 3,7
Power Consumption PBar - 11.3 12.0 Watt 4,6,7
LED Life Time LED_LT 30,000 - - Hrs 5,7

AOC E2260SWD Specifications

General

3D	No
Panel type	TN
Pixel pitch	248 x 248 mm
Aspect ratio	16:9
Backlight type	W-LED
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Maximum refresh rate	60 Hz
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	477.5 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Mean time between failures (MTBF)	50000 h
HDCP	Yes
DVI-I ports quantity	0
Tilt angle range	-5 - 15 °
Height adjustment	-
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Certification	ISO 9241-307
Product color	Black
Sustainability certificates	TCO
Package weight	4080 g

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	511 mm
Height (without stand)	373 mm
Weight (without stand)	2600 g
