4.3.4 Optical Characteristics
Ta= 25°C, V
LCD
=5.0V, fv=60Hz, D
CLK
= 72.0MHz, Is=110mA
Parameter Symbol
Values
Units Notes
Min Typ Max
Contrast Ratio CR 700 1000 -
1
(PR-880)
Surface Luminance, white LWH 200 250 - cd/m2
2
(PR-880)
Luminance Variation

WHITE
9P 75 - - %
3
(PR-880)
Response Time
Rise Time TrR - 1.3 2.6 ms
4
(RD80S)
Decay Time TrD - 3.7 7.4 ms
Color Coordinates
[CIE1931]
RED
Rx
Typ
-0.03
0.642
Typ
+0.03
(PR-650)
Ry 0.332
GREEN
Gx 0.305
Gy 0.625
BLUE
Bx 0.150
By 0.068
WHITE
Wx 0.313
Wy 0.329
Viewing Angle (CR>5)
5
(PR-880)
x axis, right(=0°)
r
75 88
Degree
x axis, left (=180°)
l
75 88
y axis, up (=90°)
u
70 85
y axis, down (=270°)
d
70 85
Viewing Angle (CR>10)
x axis, right(=0°)
r
70 85
Degree
x axis, left (=180°)
l
70 85
y axis, up (=90°)
u
60 75
y axis, down (=270°)
d
70 85
Crosstalk 1.5 % 6(PR880)
Luminance uniformity -
Angular dependence (TCO’03)
LR - - 1.7
7
(PR880)
Color grayscale linearity Δu’v’ 0.018
9
(PR-650)

AOC E2260SWD Specifications

General

3D	No
Panel type	TN
Pixel pitch	248 x 248 mm
Aspect ratio	16:9
Backlight type	W-LED
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Maximum refresh rate	60 Hz
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	477.5 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Mean time between failures (MTBF)	50000 h
HDCP	Yes
DVI-I ports quantity	0
Tilt angle range	-5 - 15 °
Height adjustment	-
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Certification	ISO 9241-307
Product color	Black
Sustainability certificates	TCO
Package weight	4080 g

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	511 mm
Height (without stand)	373 mm
Weight (without stand)	2600 g
