5. Block Diagraam
5.1 Main Board
Power Board
CRYSTAL
14.3181MHZ (X401)
Flash Memory
Pm25LD020C-SCE
(
U402
)
Scalar IC TSUMU58VHN-1
(Include ADC, OSD, MCU)
(U401)
Panel Interface
(CN410)
Key Control Interface
(CN404)
D-Sub Connector
(CN101)
Audio Connector
(CN601)
DVI Connector
(CN102)

AOC E2260SWD Specifications

General

3D	No
Panel type	TN
Pixel pitch	248 x 248 mm
Aspect ratio	16:9
Backlight type	W-LED
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Maximum refresh rate	60 Hz
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	477.5 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Mean time between failures (MTBF)	50000 h
HDCP	Yes
DVI-I ports quantity	0
Tilt angle range	-5 - 15 °
Height adjustment	-
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Certification	ISO 9241-307
Product color	Black
Sustainability certificates	TCO
Package weight	4080 g

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	511 mm
Height (without stand)	373 mm
Weight (without stand)	2600 g
