AOC i2252VWH User Manual

Service Manual AOCi2252VW
57
C908 067G215S3316LV EC 330uF 35V M 10*12.5mm 0
C927 067G215S3316LV EC 330uF 35V M 10*12.5mm 0
L901 073G 174192 H LINE FILTER 30MH MIN LCL-12012 HA 1
L901 073G 174192 X LINE FILTER 30MH MIN 3TRET20-303M-1 0
L903 073G 253 91 H IND CHOKE 3.5uH+-10% DADONG 1
L902 073G 253 91 H IND CHOKE 3.5uH+-10% DADONG 1
L902 073G 253 91 V CHOKE COIL 3.5uH+-10%
2nd source
L903 073G 253 91 V CHOKE COIL 3.5uH+-10%
2nd source
T901 080GL19P 17 N1 X'FMR 500UH 5% 10UH YUVA-1738 PQ38
2nd source
T901 080GL19P 17DN1 X'FMR 500UH 5% 10UH LZ.PJ004.R00 PQ38 1
CN901 087G 501 48 S AC SOCKET 3PIN + 3 Hole 0
CN901 087G 501 48 DL AC SOCKET 3PIN + 3 Hole 1
CN901 087G 501 48 HC AC SOCKET R/A 3P DB-14-04 H=21.6
2nd source
BD901 093G 50460 43 BRIDGE GBL208 2A/800V GBL
2nd source
BD901 093G 50460 51 BRIDGE D2SB80 2A 800V GBL 1
CN902 095G 825 7D702 HARNESS 7P(SCN)-9P(A2004) 80mm 1
705GQA57948 Q901 ASS'Y 1
051G 200 1 OIL FOR DISAPPEAR 0.1
Q901 057G 667923 MOSFET SMK0765F 7A 650V TO-220FP 0
Q901 057G 667941 MOSFET P0765ATF 7 650 TO-220F 1
0M1G 930 6120 SCREW 3x6 1
HS1 J90G0195 3 HEAT SINK 1
705GQA93507 D903 ASS'Y 1
051G 200 1 OIL FOR DISAPPEAR 0.1
D903 093G 60278 SCHOTTKY SP1060 10A 60V ITO-220AB 1
D903 093G 60507 SCHOTTKY SRF1060 C0 10A 60V ITO-220AB
2nd source
D903 093G 60526 SCHOTTKY MBRF1060CT ITO-220AB
2nd source
0M1G 930 6120 SCREW 3x6 1
HS3 J90G0195 3 HEAT SINK 1
705GQA93943 D901 ASS'Y 1
051G 200 1 OIL FOR DISAPPEAR 0.1
D901 093G 52 66 DIODE FMX-12SL 10A/200V TO-220
2nd source
D901 093G 60943 DIODE SFF1004G ITO-220AB
2nd source
D901 093G 60978 RECTIFIER UF1002FCT 10A 200V ITO-220AB 1
0M1G 930 6120 SCREW 3x6 1
HS2 J90G0195 3 HEAT SINK 1
AD11605AD2SMTJ POWER BOARD FOR SMT 1
IC901 056G 379190 AC/DC CONVERTER LD7750RGR SOP-7 1
R915 061G08051000FT RST CHIPR 100 OHM +-1% 1/8W 0
R915 061G08051000FY RST CHIPR 100 OHM +-1% 1/8W YAGEO 1
R923 061G08051002FT RST CHIP 10K 1/8W 1% 0
R923 061G08051002FY RST CHIP 10K 1/8W 1% 1
R934 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA 1
R934 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA
2nd source
R931 061G0805104 JF RST CHIPR 100KOHM +-5% 1/8W FENGHUA
2nd source
R931 061G0805104 JT RST CHIPR 100KOHM +- 5% 1/8W TZAI YUAN 1
R921 061G08051501FF RST CHIPR 1.5KOHM +-1% 1/8W FENGHUA 0
R921 061G08051501FT RST CHIPR 1K5 +-1% 1/8W TZAI YAUN 1
R920 061G0805221 JI RST CHIPR 220 OHM +-5% 1/8W 0805 1
R920 061G0805221 JT RST CHIP 220R 1/8W 5% TZAI YUAN 0
