AOC i2252VWH User Manual

Service Manual AOCi2252VW
56
9.BOM List
Note: The parts information listed below are for reference only, and are subject to change
without notice. Please go to http://cs.tpv.com.cn/hello1.asp
for the latest information.
9.1 Model：HIBGNZ6BAXK2DNJ
Location Part number Description Remark
040G 581 26704 SHIPPING LABEL
2nd source
040G 581689 4A BARCODE LABEL FOR 1 3
052G 1211 B
Conductive Tape 85mm *40mm *0.09mm (单导)
2
052G 1216 A
铝箔胶带
2
070GHDCP500HDC HDCP CODE 2
SP01 078G025A 3 YB SPEAKER 4 OHM 2.5W 40X20 380 200 1
E08904 089G 17356G554 AUDIO CABLE 1800MM 1
E08902 089G 725HAA DB D-SUB CABLE 1
E08901 089G404A15N HL AC POWER CORD 1500mm 1
ECN404 095G8014 6D724 HARNESS 6P(PH)-6P(2008) 340mm 1
0M1G1030 6120 SCREW 3x6 8
0M1G1030 8120 SCREW 1
0M1G3030 6 47 CR3 SCREW 3
0Q1G 140 14120 SCREW 6
0Q1G 930 10 47 CR3 SCREW 2
E750 750GBG215F3C13N000 LCD LM215WF3-SLC1 GZ LGD 1
756GJBCB AK002 00 MCU ASS'Y mainboard CBPCBNZK2J1 0
U402 056G2233501 FLASH MX25L2026DM1I-12G 2Mb SOP-8 1
SMTCB-U402 100GANGI001B11 AOC_i2252Vwh_NT68677_LPL_LM215WF3_SLC1 0
CBPCBNZK2J1 CONVERSION G4641-M01-000-0040-1-110808 1
ADPC11605AD2J POWER G4750-P02-000-0010-110531 1
GND2 009G6005 1 GROUND TERMINAL 1
GND1 009G6005 1 GROUND TERMINAL 1
IC902 056G 139 3A PC123Y22FZOF SHARP 1
NR901 061G 58100 X NTCR 10R 20% 5W(10D2-14 MCS) 0
NR901 061G 58100MEW NTCR 10R 20% 4W 1
C905 063G107K224 UM X2 CAP 0.22uF K 275VAC 1
C905 063G107K2246S1 X2 CAP 0.22UF K 275VAC 0
C921 065G306K6812BP Y1 680PF M 250VAC 1
C920 065G306K6812BP Y1 680PF M 250VAC 1
C921 065G306K6812BW CAP Y1 680PF 10% 250V Y5P
2nd source
C920 065G306K6812BW CAP Y1 680PF 10% 250V Y5P
2nd source
C900 065G306M3322BP CAP Y1 3.3NF 20% 250V Y5U 1
C900 065G306M3323BW CAP Y1 3.3NF 20% 250V Y5U
2nd source
C903 067G 40Z47015H EC 47UF 20% 450V 13*36
2nd source
C902 067G 40Z47015H EC 47UF 20% 450V 13*36
2nd source
C903 067G 40Z47015K EC 47UF 20% 450V 12.5*35 1
C902 067G 40Z47015K EC 47UF 20% 450V 12.5*35 1
C902 067G 40Z47015L EC 47UF 20% 450V 12.5*35
2nd source
C903 067G 40Z47015L EC 47UF 20% 450V 12.5*35
2nd source
C907 067G215S3316KV EC 330uF M 35V 10*12mm 1
C908 067G215S3316KV EC 330uF M 35V 10*12mm 1
C927 067G215S3316KV EC 330uF M 35V 10*12mm 1
C907 067G215S3316LV EC 330uF 35V M 10*12.5mm 0
