Service Manual AOCi2252VW
8
2. Operation instruction
2.1 Connection
Connect the video cable ②or③or④ from the video card of PC to the monitor..
The power cord ① should be connected ,
Audio input cable ⑤ can be connected
Press the power button to turn on the monitor, the power indicator will light up.
2.2 Control Buttons
Control Button Description
1
To turn ON/OFF the moniteor, and power indicator
(Green/Orange).
2
Menu / Enter
Active main menu while no OSD display,enter next level on
main menu or sub menu status, or enter last level on
adjustment bar. Select Exit icon then press Menu button to
return to superior menu.
3
Auto/Exit
Hotkey ,Input Source selection.D-SUB/DVI/HDMI
There is OSD, press Auto button to exit OSD.
4
+/Volume
/up
Hotkey, chang Volume +
OSD, increase current value of bar, or move to next item of
menu
5
-/Down
Hotkey, Clear Vision function ; chang Volume -;
OSD, it will decrease current value of bar, or it will move to
last item of menu.
