59
LE32A3520/61
Item Description
1 BEZEL
2 LENS IR
3 LENS LED
4 IR BOARD
6 SPEAKER
Item Part No. Description Qty
8 COVER KEY 5 0Q1G1030 8120 SCREW(IR BOARD-BEZEL) 1
9 KEY 7 001G6021 1 SCREW(SPEAKER-BEZEL) 4
10 KEY BOARD 13 0Q1G 330 8120 SCREW(BRACKET HOLDER_TOP-BEZEL) 3
11 PANEL 15 0Q1G 330 8120 SCREW(BKT_HOLDER -BEZEL) 5
12 BRACKET HOLDER_TOP_DYNEX 18 0Q1G 330 8 47 CR3 SCREW(BKT_OPS_CHASSIS-COMPONENT) 1
14 BKT_HOLDER Ÿ 19 0M1G1730 6120 SCREW(MAIN BOARD-PANEL) 3
16 MAIN BOARD 20 0M1G1730 6120 SCREW(BKT_OPS_CHASSIS-PANEL) 1
17 BKT_OPS_CHASSIS 22 0M1G1730 8120 SCREW(BRACKET PB_BTM-PANEL) 2
21 BRACKET PB_BTM 23 0M1G1730 6120 SCREW(BKT_OPS_CHASSIS-PANEL) 1
24 AC COVER 25 0M1G 940 6 47 CR3 SCREW(AC COVER-BRACKET PB_BTM) 1
26 POWER CORE 29 0M1G1730 6120 SCREW(POWER BOARD-PANEL) 6
27 MYLAR 31 0M1G1730 8120 SCREW(BRACKET STAND-PANEL) 4
28 POWER BOARD 33 0Q1G 940 10 47 CR3 SCREW(REAR COVER-BEZEL) 14
30 BRACKET STAND 34 0M1G 940 6 47 CR3 SCREW(REAR COVER-AC STAND) 1
32 REAR COVER 35 0Q1G 330 8 47 CR3 SCREW(REAR COVER-HDMI) 2
37 STAND 36 0M1G 330 8 47 CR3
SCREW(REAR COVER-YPbPr）
2
39 BASE 38 0M1G1740 12225 CR3 SCREW(STAND-AC STAND) 4
41 FOOT PAD 40 0Q1G 940 18 47 CR3 SCREW(BASE-STAND) 4
42 BRACKET HOLDER_BTM_DYNEX 43 Q02G7022 3 SCREW(PANEL) 1
To Next Page
