15
APPENDIX
SPECIFICATIONS
CRT Size
35.5cm(14"), 90º deflection,
29mm neck
CRT Viewable Image
Size
33.5cm (13.2"), diagonal
Type 0.28mm dot pitch
Video 0.7Vpp, R,G,B Analog
Input Separate Sync. TTL Level
H./V.- Sync. Positive / Negative
Scanning H-Frequency 30kHz - 54kHz
Frequency V-Frequency 50Hz-120Hz
Max. Resolution 1024 x 768
Video Dot Rate 65MHz
Factory Preset mode : 5
User Programmable mode : 12
Power Source Universal AC 100 - 240V,
50Hz / 60Hz
Operating 0°C to 40°C ambient
Humidity 10%to 85%relative, non-condensing
Dimensions Monitor & Base 350(W) × 349(H) × 377(D)mm
Weight Unit(net) 10.5kgs(net)
Signal Cable: Attached Mini D-sub 15 Male
350
349
(ln mm)
377
