AOC SPECTRUM SERIES User Manual

35
APPENDIX
SPECIFICATIONS
CRT Size
38.1cm(15"), 90º deflection,
29mm neck
CRT Viewable Image
Size
35.1cm (13.8"), diagonal
Type 0.28mm dot pitch
Video 0.7Vpp, R,G,B Analog
Input Separate Sync. TTL Level
H./V.- Sync. Positive / Negative
Scanning H-Frequency 30kHz - 54kHz
Frequency V-Frequency 50Hz-120Hz
Max. Resolution 1024 x 768
Video Dot Rate 65MHz
Factory Preset mode : 5
User Programmable mode : 12
Power Source Universal AC 100 - 240V,
50Hz / 60Hz
Operating 0°C to 40°C ambient
Humidity 10%to 85%relative, non-condensing
Dimensions Monitor & Base 360(W) × 362(H) × 387(D)mm
Weight Unit (net) 11.5kgs ( Net )
Signal Cable: Attached Mini D-sub 15 Male
362
360 387
(ln mm)
