6
15-pin color display signal cable
PIN No. Description PIN No. Description
1 Red 9 +5V for DDC
2 Green 10 GND
3 Blue 11 NC
4 NC 12 SDA
5 GND 13 H-sync
6 R-ground 14 V-sync
7 G-ground 15 SCL
8 B-ground
