22
M
M
X
X
4
4
G
G
V
V
R
R
O
O
n
n
l
l
i
i
n
n
e
e
M
M
a
a
n
n
u
u
a
a
l
l
C
C
P
P
U
U
I
I
n
n
s
s
t
t
a
a
l
l
l
l
a
a
t
t
i
i
o
o
n
n
This motherboard supports Intel
®
Pentium 4 Socket 478 series CPU (Willamette / Northwood). Be careful of CPU orientation when
you plug it into CPU socket.
2. Locate Pin 1 in the socket and look for mark on the CPU upper interface.
Match Pin 1 and cut edge, then insert the CPU into the socket.
1. Pull up the CPU socket lever and
up to 90-degree angle.
CPU pin 1 and
cut edge
CPU socket
Lever
CPU cut edge
Note: Those pictures are for example only; they may not look the same with the motherboard you purchased.
