This motherboard provides USB and PS2 keyboard / mouse wake-up function. You can use JP27 / JP28 to enable or disable the
resuming of your system from suspend mode with any USB keyboard or mouse connected. JP28 controls 1
st
USB channel, and
JP27 controls 2
nd
USB channel. The factory default setting is set to “Disable”(1-2), and you may enable this function by setting the
jumper to 2-3.
