If the housing has been designed with an audio port on the front panel, you’ll be able to connect onboard audio to front panel
through this connector. By the way, please remove 5-6 and 9-10 jumper caps from the Front Audio Connector before connecting the
cable. Please do not remove these 5-6 and 9-10 yellow jumper caps if there’s no audio port on the front panel.
Pin 1
AUD_RET_R
AUD_VCC
AUD_GND
AUD_FPOUT_L
HP_ON
2
1
10
9
KEY
AUD_RET_L
AUD_MIC
AUD_MIC_BIAS
AUD_FPOUT_R
Note: Please remove the jumper cap from the front audio connector before
you connect the cable. Do not remove this yellow jumper cap if your housing
doesn
’
t have an audio
p
ort on the front
p
anel.
