Switching on - off
Switch on the electric system supply
on the battery
Activate the battery by pressing the button on its body.
Switch on the LCD display of eBike
Press the button on the display controller and hold it for 2 seconds.
Use the same method to switch off the electric system. To switch off the frame battery press the button for
period of 4 seconds. Due to energy saving switches the system off automatically after 10 minutes of inactivity.
Assistance level setting
To change the assistance level in the range 0-5 shortly press button . The highest assistance level is 5,
level 0 is without the motor assistance.
In case of ride with low rotation speed and high assistance mode the motor can vibrate for
a short term. In that event we recommend to reduce the assistance level immediately.
Off-road mode (only series E3)
To enter off-road mode select the assistance mode 5 and press button . The assistance mode indicators
starts to display flashing digit 6. To confirm it press again button .
In this mode is the nominal motor performance up to 350W.
It can be used only outside the public roads!
CODAC - EBIKE CONTROL
1
2
frame battery
seat tube battery
mph
km/h
TRIP ODO TIME MAX AVG RANGE ERROR
mi/h
km/h
speed units
walking assistance
speed / distance units
power scale
assistance level
battery status
lights
speed
speed / distance
speed / distance mode
error code
USB port
(Hawk E3/E5, Manitou E3/E5, Yamka E3/E5, Matto E3/E5, Matto E3/E5 Lady, Tate 24”, Tate 27.5”,
Gaagii, Gaagii Lady, Wakita Tour, Wakita City, Wakita Grace, Wakan City)
5
