TFT COLOUR - EBIKE CONTROL
Switching on - off
Switch on the electric system supply
on the battery
Activate the battery by pressing the button on its body.
Switch on the TFT display of the eBike
On the display controller press button and hold it for 2 seconds.
Use the same method to switch off the electric system. To switch off the frame battery press the button for
period of 4 seconds. Due to energy saving switches the system off automatically after 10 minutes of inactivity
(this time can be set by user - see parameter setting below).
Assistance level setting
To change the assistance level in the range 0-5 shortly press button . The highest assistance level is 5,
level 0 is without the motor assistance. After switching on the display is the assistance level automatically set to
level 1.
In case of ride with low rotation speed and high assistance mode the motor can vibrate for
a short term. In that event we recommend to reduce the assistance level immediately.
Walking assistance
To activate the walking assistant press shortly and hold button on the control display. This function simplifies to
handle the eBike, usually during walk along the eBike. EBike moves along in such a case by speed around 4 to
6 km/h. The walking assistance is deactivated as soon as the button is released.
ATTENTION: After activating the walking assistant do not try to prevent the bike to move.
It can cause motor damage.
1
2
frame battery
on/off
13:14
76%
48.2
km/h
TRIP 265.9Km
4
5
10
15
20
25
30
0
250
500
750
km/h
w
battery statustime
USB charging
lights
voltage indicator
/ battery status in %
speed scale
display mode
power scale
data indication
assistance level
seat tube battery
(Hawk MX, Manitou MX, Yamka MX, Matto MX, Matto MX Lady, Wakita Tour MX, Wakan Tour MX,
Wakita Grace MX, Wakan Grand MX)
7
