Apache RTR 180 User Manual

10. PARTS CHANGE DETAILS
WHEEL ASSEMBLY REAR (TUBELESS)
1.
Wheel assembly rear : N9112750
Alloy wheel rear
: N9112840
Tyre rear
: N9112920
2.
New parts changed to suit tubeless tyre assembly.
3.
Rear wheel size changed from 100 / 80 -18" to
110 / 80 -17"
4.
Can be identified the "Tubeless" & by pr file
f Wheel
rim at the valve mounting area.
5.
Not interchangeable with existing RTR vehi le as an
individual parts. But as an wheel assembly
an be used.
6.
Valve (Tubeless tyre) will be servi
ed under this part
No. N9112880
SAREE GUARD COMPLETE
1.
Saree guard compl te : N9221710
2.
No Change in Part No.
3.
Saree guard is modified to new styling.
4.
The mod f ed part can be interchanged with
exist ng RTR 160 vehicles.
5.
Only mod f ed part will be serviced in spares.
If you face any critical problems during the course of
servicing and n d furth r clarification or technical assistance
you may contact our Area service personnel
You may contact us at
TVS Motor company limited
Marketing (Service) Limited
Post box No.4, Harita
Hosur - 635 109
Tamilnadu, India
-20-

Apache RTR 180 Specifications

General

Engine Displacement	177.4 cc
Engine Type	4-stroke, Single Cylinder
Max Torque	15.5 Nm @ 7000 rpm
Fuel System	Carburetor
Cooling System	Air Cooled
Transmission	5-Speed
Front Brake	Disc
Fuel Tank Capacity	12 liters
Bore x Stroke	62.5 mm x 57.8 mm
Compression Ratio	9.5:1
Front Suspension	Telescopic Forks
Front Tyre	90/90-17
Rear Tyre	110/80-17
Overall Length	2085 mm
Overall Width	730 mm
Wheelbase	1326 mm
Ground Clearance	165 mm
Seat Height	800 mm
Max Power	17.03 PS @ 8500 rpm
Ignition	Digital
Starting	Electric Start
Clutch	Wet multi-plate
Frame Type	Double cradle
