Apache RTR 180 User Manual

10. PARTS CHANGE DETAILS
REAR FENDER
1.
Rear fender : N9222000
2.
New part due to styling
3.
Not interchangeable with existing RTR 160 vehicles.
FLAP REAR FENDER
1.
Flap rear fender : N9222010
2.
New part to suit n w r
ar f nd r.
3.
Not interchang able with
xisting RTR 160 vehicles.
4.
Rear fender & Flap r ar f
nd r matching bracket will be
serviced under this part No. N9222040
COVER ILLUMINATOR
1.
Cover illuminator : N9222020
2.
New part to suit new rear fender.
3.
Not interchangeable with existing RTR 160 vehicles.
WHEEL ASSEMBLY FRONT (TUBELESS)
1.
Wheel assembly front : N9112890
Alloy wheel front
: N9112860
Tyre front
: N9112910
2.
New parts due to introduction of tubeless tyre assembly.
3.
Front wheel size ( 90/90-17 ) is same as Apache RTR 160 cc
4.
Can be identified the "Tubeless" & by profile of Wheel
rim at the valve mounting area.
5.
Not interchangeable with existing RTR vehicle as an
individual parts. But as an wheel assembly can be used.
6.
Valve (Tubeless tyre) will be serviced under this part
No. N9112880
-19-

Apache RTR 180 Specifications

General

Engine Displacement	177.4 cc
Engine Type	4-stroke, Single Cylinder
Max Torque	15.5 Nm @ 7000 rpm
Fuel System	Carburetor
Cooling System	Air Cooled
Transmission	5-Speed
Front Brake	Disc
Fuel Tank Capacity	12 liters
Bore x Stroke	62.5 mm x 57.8 mm
Compression Ratio	9.5:1
Front Suspension	Telescopic Forks
Front Tyre	90/90-17
Rear Tyre	110/80-17
Overall Length	2085 mm
Overall Width	730 mm
Wheelbase	1326 mm
Ground Clearance	165 mm
Seat Height	800 mm
Max Power	17.03 PS @ 8500 rpm
Ignition	Digital
Starting	Electric Start
Clutch	Wet multi-plate
Frame Type	Double cradle
