Connections
Front panel
1. Output status: These leds indicate the status of the output
zones. When a zone is active the corresponding led will be lit.
The leds also indicate the status of the amplifiers, when an
amplifier is short circuited, the output led will start to blink.
2. Power led: lights up when mains power is present and the unit
has been switched on.
3. Removable rack ears left and right.
1 2 33
