FREQUENCY RESPONSE 40HZ 25KHZ (+1/-3 DB)
DISTORTION <0,3% @ -6DB, 1KHZ
BASS CONTROL +/- 10DB, 100 HZ
TREBLE CONTROL +/- 10DB, 10 KHZ
S/N amplier: better than 95dB, 22Hz 22kHz
line: better than 80dB, 22Hz 22kHz
mic: better than 65dB, 22Hz 22kHz
LED INDICATORS limiter active, red
signal 100%, yellow
signal -25 dB, green
power on, green
protection active, red
ZONE ACTIVE INDICATORS Z1, Z2 and Z3 green LED
Z4 music on/off, orange
Z4 paging allowed on/off, orange
MUTED BY PRIORITY LED any of the priority modes active, red
POWER SUPPLY 230V/ 50-60HZ MAX750VA
WEIGHT approx.12,7 kg
DIMENSIONS 430(W) x 88(H) x 356(D)mm
19” wide, 2U high
OPERATING TEMPERATURE -10 to +45°C
8. Technical Specifications
General
