APART MA200 - Input Specifications

INFO@APART-AUDIO.COM
MIC INPUT 1; ¼” TRS PHONE JACK AT THE FRONT
XLR3 COMBO, DIN5; EURO BLOCK
SENSITIVITY 1,5 MV
IMPEDANCE 600 Ω
S/N (AT MAX. VOLUME) > 65 dB
PHANTOM POWER 14 V (internal jumper)
FREQUENCY RESPONSE > 80Hz->15Khz (+1/-3 dB)
VOX MUTE trigger level 0,6 mV, 1Khz, mutes mic 2,3,4+music, > 40 dB
Mic input 2,3 & 4: XLR3 balanced
SENSITIVITY 1,5 mV
IMPEDANCE 600 Ω
S/N (AT MAX. VOLUME) > 65 dB
PHANTOM POWER 14 V (internal jumper)
FREQUENCY RESPONSE > 80Hz->15Khz (+1/-3 dB)
Emergency input; euro block
SENSITIVITY 1 V
IMPEDANCE 600 Ω
S/N (AT MAX. VOLUME) > 80 dB
FREQUENCY RESPONSE > 100Hz-> 25Khz (+1/-3 dB)
MUTE mutes all, > 40 dB
AUX INPUT; RCA
SENSITIVITY 500 MV (-6 DB)
IMPEDANCE 22 KΩ
S/N (AT MAX. VOLUME) > 80 DB
FREQUENCY RESPONSE > 40HZ-> 25KHZ (+1/-3 DB)
LINE 4; RCA
SENSITIVITY 200 MV (-14 DB)
IMPEDANCE 47 KΩ
S/N (AT MAX. VOLUME) > 80 DB
FREQUENCY RESPONSE > 40HZ-> 25KHZ (+1/-3 DB)
CD IN
SENSITIVITY 500 MV (-6 DB)
IMPEDANCE 5 KΩ
S/N (AT MAX. VOLUME) > 80 DB
FREQUENCY RESPONSE > 40HZ-> 25KHZ (+1/-3 DB)
TUNER
SENSITIVITY 300 MV (-6 DB)
IMPEDANCE 30 KΩ
S/N (AT MAX. VOLUME) > 80 DB
FREQUENCY RESPONSE > 40HZ-> 25KHZ (+1/-3 DB)
Inputs
