APART MA200 - Output Specifications; Speaker Selector and Outputs; Priority System and Chime

WWW.APART-AUDIO.COM
SPEAKER SELECTOR
ZONE 1 3 on/off
ZONE 4 paging on/off music on/off
SPEAKER ZONE OUTPUT, EURO BLOCK
HIGH Z ZONE 1-2-3-4 100 V
SPEAKER OUT; EURO BLOCK
HIGH Z 50 (12,5 Ω) 70 (24,5 Ω) 100 V (50 Ω)
LOW Z 8 Ω
PHANTOM POWER
MIC 1-2-3-4 14 V; internal jumpers
PRE AMP OUT
LEVEL 1 V
RECORD OUT; RCA MONO
LEVEL 1 V
PRIORITY OUT
LEVEL 24 V DC; max 1A, short circuit protected
CHIME
2 tone
activated by contact closure;
euro block DIN5
on/off and level set by trimmer
PRIORITY
I Emergency input / telephone
200 mV; 1 kHz VOX threshold
mutes all other signals
> 40 DB
II Vox mute only for mic 1
0,6 mV; 1 kHz VOX threshold
mutes mic 2,3 & 4 + music
on/off/level set by trimmer
> 40 dB
III Priority contact
> 40 dB
mutes all music inputs
Outputs
