3.0 Presentation
3.1 600VA UPS—100 and 120 Vac versions
Rear view
NEMA 5-15R
receptacles
Computer
Interface port
See Sec. 6.4
UPS enable switch
see Sec. 4.3
Site wire fault light
see Sec. 4.5
Option switches
see Sec. 5.5
IEC 320 inlet
Circuit breaker
Display
features
see Section 5.1
Test
button
see Sec. 5.1.8
Alarm disable
button
See Sec. 5.1.9
Power on
button
see Sec. 5.1.6
Power standby
button
see Sec. 5.1.7
Front view
