Apeks DUPLEX 2000PSI - Separator Vessel;Control Stand

Apeks Supercritical: The Duplex™ Installation Manual
7
Revision Date 04/11/2019
2.1.3. Separator Vessel/Control Stand
Bank 1
Bank 2
E-Stop
Evacuation Valve
Vent Valve
Flow Switch
Collection Cup
Water Valves
Cup Lift
Control Panel Mount
Figure 5: Extraction Vessels and Control Panel
