api technologies corp. 7608AD Series - MASTER;SLAVE CONFIGURATION; PDU ADDRESS

Installation and Operation Manual
ECN: 003155
Date: 06/4/2013
13
AC-SmartStart-7608-Series_IOM Rev 04
13
AFFH1 Configures the EPO setting so that when the EPO communi-
cation setting is 1, the UFFEPO response is issued for every
command received during the EPO condition
UFFH1 or
UFFEPO
AFFH2 Configures the EPO setting so that user intervention is required
before the unit will re-sequence back on.
UFFH2
REMOTE TEMPERATURE SETTINGS
AFFK Returns the current over temperature setting. UFFK FF
AFFK 37 Changes the value of the over temperature setpoint to 37 Hex.
37 = 55 degrees C Valid range from 00 to FF hex. FF = off/
sensor not connected.
UFFK 37
MASTER/SLAVE CONFIGURATION
AFFM Returns the master/slave setting UFFM0
AFFM0 Changes the master/slave setting to a stand alone unit UFFM0
AFFM1 Changes the master/slave setting to a master UFFM1
AFFM2 Changes the master/slave setting to a slave UFFM2
PDU ADDRESS
AFFN Returns the current address of the PDU UFFNFF
AFFNAA Changes the address of the PDU to AA. Valid range from 00 to
FF hex.
UFFNAA
TURN ON OUTLETS
AFFP Sequences outlets 1 through 8 on in the order of the pro-
grammed start up sequence.
UFFP
AFFPA Sequences outlets 1 through 4 on in the order of the pro-
grammed start up sequence.
UFFPA
AFFPB Sequences outlets 5 through 8 on in the order of the pro-
grammed start up sequence.
UFFPB
SEQUENCE OFF OUTLETS
AFFQ Sequences the outlets off in the reverse order of the start up
sequence.
UFFQ
AFFQA Sequences outlets 1 through 4 off in the reverse order of the
start up sequence.
UFFQA
AFFQB Sequences outlets 5 through 8 off in the reverse order of the
start up sequence.
UFFQB
DIRECT OUTLET ACCESS
AFFr01 Returns the status of outlet #1 UFFr01 1
AFFr01 0 Turns outlet #1 off UFFr01 0
AFFr01 1 Turns outlet #1 on UFFr01 1
AFFr02 Returns the status of outlet #2 UFFr02 1
AFFr02 0 Turns outlet #2 off UFFr02 0
AFFr02 1 Turns outlet #2 on UFFr02 1
AFFr03 Returns the status of outlet #3 UFFr03 1
AFFr03 0 Turns outlet #3 off UFFr03 0
AFFr03 1 Turns outlet #3 on UFFr03 1
Operational Commands
