Installation and Operation Manual
ECN: 003155
Date: 06/4/2013
14
AC-SmartStart-7608-Series_IOM Rev 04
AFFr04 Returns the status of outlet #4 UFFr04 1
AFFr04 0 Turns outlet #4 off UFFr04 0
AFFr04 1 Turns outlet #4 on UFFr04 1
AFFr05 Returns the status of outlet #5 UFFr05 1
AFFr05 0 Turns outlet #5 off UFFr05 0
AFFr05 1 Turns outlet #5 on UFFr05 1
AFFr06 Returns the status of outlet #6 UFFr06 1
AFFr06 0 Turns outlet #6 off UFFr06 0
AFFr06 1 Turns outlet #6 on UFFr06 1
AFFr07 Returns the status of outlet #7 UFFr07 1
AFFr07 0 Turns outlet #7 off UFFr07 0
AFFr07 1 Turns outlet #7 on UFFr07 1
AFFr08 Returns the status of outlet #8 UFFr08 1
AFFr08 0 Turns outlet #8 off UFFr08 0
AFFr08 1 Turns outlet #8 on UFFr08 1
OUTLET STATUS
AFFS Returns the status of the unit. The status is displayed in HEX
format. The fifth digit represents outlets 8 through 5 MSB to
LSB, and the sixth digit represents outlets 4 through 1 MSB
to LSB. If the outlet is on the bit representing that outlet is
turned on (0 = no, 1 = yes). The seventh digit represents
remote ® or local (L) mode.
UFFSFFR
AFFS00 Turns all relays off simultaneously. The last two digits of the
command are in hex format and will control all 8 relays. This
command is useful to control multiple relays at the same time.
Any two digit hex number conbination can be used between
00 to FF.
UFFS00R
TEMPERATURE MEASUREMENT
AFFt Returns the temperature reading from the optional external
temperature probe. (0 to 100 C)
UFFt 000.0 C Temp
OUTLET SEQUENCE CONFIGURATION
AFFT01 Returns the value of the first outlet to turn on UFFT01
AFFT02 Returns the value of the second outlet to turn on UFFT02
AFFT03 Returns the value of the third outlet to turn on UFFT03
AFFT04 Returns the value of the fourth outlet to turn on UFFT04
AFFT05 Returns the value of the fifth outlet to turn on UFFT05
AFFT06 Returns the value of the sixth outlet to turn on UFFT06
AFFT07 Returns the value of the seventh outlet to turn on UFFT07
AFFT08 Returns the value of the eighth outlet to turn on UFFT08
AFFT01 08 Sets outlet #8 to turn on first in the programmed sequence. UFFT01 08
AFFT02 07 Sets outlet #7 to turn on second in the programmed se-
quence.
UFFT02 07
AFFT03 06 Sets outlet #6 to turn on third in the programmed sequence. UFFT03 06
Operational Commands
