Apollo 7300ETL User Manual

20
APOLLO Gate Operators RECEIVER OPTIONS
Do not confuse the receiver code switches with the red program switches on the gate control board.
Never set all code switches to the same position. Transmitters must match code switches for proper operation.
If power is taken directly from battery or connected as shown below, receiver should be configured for 12VDC
Multi-Code/Digi-Code
Allister
Lift-Master
black
gray
gray
red
white
black
red
4
3
2
1
Heddolf
Linear
black
yellow
red
white/silver
common
n/o
white/gold
white

Apollo 7300ETL Specifications

General

Brand	Apollo
Model	7300ETL
Category	Gate Opener
Language	English
