Introduction
Apollo GX50/60/65 Installation Manual
7
Table 1 Package Contents
Part # Description Qty
GX50 GX60 GX65
Units
430-6050-4xx GX50 GPS 1
430-6050-6xx GX60 GPS / Comm 1
430-6050-8xx GX65 GPS / Comm 1
Install kits Part number: 424-2007- -4xx -6xx -8xx
162-0100 15-pin dsub connector shell 1 1
162-0103 37-pin dsub connector shell 1 1 1
162-1008 Right angle coax plug 1 2 2
162-1060 TNC coax connector 1 1 1
202-0001 Cable tie 2 4 4
204-0037 Edge grommet 6” 6” 6”
204-2100 Shoulder bushing 2 4 4
221-0400 4-40 x 1/4 SS pan head Phillips machine screw
with lock washer
888
224-0404 4-40 x 1/4 SS flat head Phillips machine screw 2 4 4
245-0022 Crimp contact for dsub, 20 to 24 awg wire 37 52 52
310-5184-00 Mounting frame 1 1 1
310-5188-00 Connector mounting plate 1 1 1
998-0048 3/32 hex driver 1 1 1
Manual kits Part number: 564-0064- -4xx -6xx -8xx
560-0961-xx GX GPS User’s Manual 1 1 1
560-0959-xx GX50 / GX60 Installation Manual 1 1 1
560-0928-xx GX GPS Approach User’s Manual Insert 1 1
560-0963-xx GX60 Comm User’s Manual Insert 1 1
560-9000 Binder, 5½ x 8½ x 1” 3 ring 1 1 1
561-0236-xx GX60/65 Quick Reference Guide 1 1
561-0238-xx GX50 Quick Reference Guide 1
Accessories
560-0949-xx A-33 Installation Guide 1 1 1
590-1104 A-33 GPS Antenna 1 1 1
Note: Package contents may vary depending on how the unit is ordered.
